068U1771

Temperature range –40 - 10°C. Max. working pressure 34.0 bar. The rated capacity is based on: Evaporating temperature te = +5°C. Condensing temperature tc = +32°C. Refrigerant liquid temperature tl = +28°C. Opening superheat OS = 4 K. External equalization connection size, TUBE versions with mm-connections: 6 mm, versions with in.-connections: 1/4 in.
